Rough Terrain Pallet Truck

Rough Terrain Pallet Truck - All Terrain Forklift - BALL-T series

Beacon® BALL-T Series

The Rough Terrain Pallet Truck - All Terrain Forklift easily move heavy loads over uneven surfaces. This series is excellent for use at construction sites, nurseries, gravel pits, and any other rough-terrain environment. Units feature a 3 position handle for Up, Down, and Neutral.
Starting at: $2,117.70

See chart below and click a model number

Product Details

  • Construction: Units feature sturdy steel construction. Tubular frame is designed to handle evenly distributed loads easily.
  • Size: These units are either 63-3/4" or 64" wide, 49" or 50" long, and 51" high.
  • Service Range: The service range is 3" to 9" for both models.
  • Overall Fork Width: Forks are 4" wide x 2" high on the BALL-T-2 and 4-3/4" wide x 2" high on the BALL-T-HD. Adjustable forks are 9-1/2" minimum and 26" maximum on BALL-T-2 and 12" minimum and 26-3/4" maximum on BALL-T-HD.
  • Overall Fork Length: Forks are 32" long on the Rough Terrain Pallet Truck.
  • Color: Models are powder coated Beacon yellow for high visibility.
  • Weight: Models are either 328 or 519 lbs. Optional tow bar adds 20 lbs.
  • Capacity: Manual models have capacities of 2,000 or 2,500 lbs. at 12" horizontal load center, 1,500 or 2,000 at 15", and 1,000 or 1,5000 at 24".
  • Standard: BALL-T-2 features 16" x 8-1/2" front wheels. BALL-T-HD has 22-3/8" front tires. Back steering wheels are 10". Inside straddle is 50" and outside straddle is 64" on both models.
  • Options: The optional tow bar allows the Rough Terrain Pallet Truck unit to be towed by either a small utility tractor or an ATV. Units may be pulled when loaded or unloaded.

Documents


Options


Rough Terrain Pallet Truck - BALL-T Series
Model No. Capacity (LBS) Adjustable Fork Width Fork (W x L) Service Range Overall Size (W x L x H) Powder Coat Finish Price
1) BALL-T-2 2,000 9½" to 26" 4"x32" 3" to 9" 63¾"x49"x51" Yellow $2,117.70
OPTION
Model No. Description Size (L x W x D) Price
2) BALL-TTB Tow Bar Package 40½"x4½"x5" $165.33
