Portable Platform - Folding Work Platform - BWP series

Beacon® BWP-FD Series

Portable Platform - Folding Work Platform raises workers to overhead racks and shelving for convenient access. This series features knock-down design, enabling it to take up a minimum of storage space. Unit stores conveniently in a 4" deep bottom base, with an overall height of 11-9/16". The handrails are 38" high with a 23-1/2' mid rail on three sides.
Starting at: $1,044.13

See chart below and click a model number

Product Details

  • Construction: The unit's floor is checker plate. The tine lock and a safety restraint to attach the platform the fork truck.
  • Size: The overall platform size is 37" wide x 37" long. The folded size is 38" wide x 38" long x 11-5/8" high. The safety expanded metal backing is 60" or 84" high (81-1/2" or 89" overall). Usable fork pockets are 7-7/8" wide x 3-3/8" high with 27-3/4" centers.
  • Color: The unit has a powder coated Beacon yellow finish.
  • Surcharge: Due to supply chain disruption, inflation or material shortages - tariffs or surcharges may apply to current published pricing. Some longer lead times may be incurred. Freight charges will be added to published pricing.

Documents


Options


Portable Platform - BWP-FD Series
Model No. Platform Size (W x L) Fork Pocket Center Expanded Metal Back Capacity (LBS) Price
1) BWP-3737-FD 37"x37" 27¾" 81½" 600 $1,044.13
2) BWP-3737-FD-84B 37"x37" 27¾" 39" 600 $1,136.98
OPTION
Model No. Description Price
3) BWP-CAFD Optional Casters, 2 rigid and 2 swivel, 4" x 2" $162.71
