Heavy Duty Scissor Lift

    Homepage–>Scissor Lifts–>Heavy Duty Scissor Lift
Product: Heavy duty scissor lift
Beacon Model: Beacon BMLTQD series heavy duty scissor lift.
Description: The Beacon long super heavy duty scissor lift table is an electro-hydraulic scissor lift designed for extreme lifting. These electric scissor lift models have a have design safety factor of 3 to 1. The surfaces are degreased, oxide-primed and finished with 2 enamel coats. This heavy duty scissor lift is supplied with standard straight toe guards for surface mounting. If pit mounting is required, please specify when ordering, and beveled toe guards will be supplied at no charge. Call Beacon for optional electric toe guard pricing.
Construction: The heavy duty scissor lift features steel construction.
Size: The heavy duty scissor lift is available in a variety of standard platform sizes ranging from 96" x 120" to 96" x 216" and in maximum platform sizes ranging from 120" x 168" to 120" x 264".
Service Range: The heavy duty scissor lift models come in lowered heights of 16" or 20" and in a variety of raised heights ranging from 46" to 92".
Capacity: The heavy duty scissor lift tables are available in a variety of capacities ranging from 50,000 to 120,000 lbs.
Electrical: 230 / 480 Vac, 3 Phase, 60 Hz is standard. Other electrical options are available.
Powered: Optional Air (Rotary Air/Oil or Reciprocating Air/Oil) is available at an additional charge.
Installation: Surface or pit mount will end up with different overall heights. The three vertical geometric propeties to be aware of is the (1) Lowered height (2) Travel (3) Overall height. When mounting in a pit, your travel will end up as your overall height.
Weight: The heavy duty scissor lifts come in a variety of weights ranging from 12,000 to 20,800 lbs.
Scope: It is the customer's responsibility to meet all federal, state and local codes regarding height restrictions and safety requirements.
Note: Payment Terms: This product is special and requires a 20% deposit at time of order, 20% prior to shipment and balance net 30 with approved credit.
Warranty: To Keep warranty valid you cannot cantilever the geometric ratio weight beyond the center of gravity. All Hydraulic Lift Tables are quoted the capacity within its deck size.
Usage: It is the customer’s responsibility to verify correctness of fit for applications. It is the customer's responsibility to verify that this unit complies with all safety laws, codes and regulations.
Prices may increase due to steel surcharge.
